Specifications

Input Voltage:                    AC 220/380V

Frequency:                         50/60Hz

Rated Power:                     5KVA

Fuse:                                  10A

Welding Current:               15-270A

Duty Cycle:                         35%

Insulation Grade:                F

Wire Diameter:                   0.8 / 1.0mm

Wire Feeding Mechanism:  inner

Package Size:                      470*770*790cm

Weight:                               70KG

Features

1. For all position fast welding and electric welding of thin plate to medium plate, suitable for welding soft steel, low alloy structural steel, high strength steel of Di alloy, etc.

2. This machine has an integrated structure, wire feeding circuit using pwm carving, wire feeding force is large, effectively ensure the smooth wire feeding speed in the welding process.

3. Adjust the welding time and intermittent time on the panel, this function is designed for sheet spot welding, no need for long seam welding use.

4. This machine is widely used in steel structure, petrochemical, automobile, shipbuilding, machinery manufacturing and so on.

5. Unique automatic detection of power grid voltage function, multi-layer bridge rectifier, equipped with heating decompression meter.
