Lifting Capacity: 3500kg
Motor Power: 3.0kw-380v or 3.0kw-220v
Oil Pressure Rating: 24MPa
Air Pressure: 0.6-0.8MPa
Product Details
Features
1.Ultrathin structure, surface mount, the initial landing height is 105mm, occupied small space.
2.The Italy original imported hydraulic pump valve and electrical components.
3.Double cylinder drive, safe and stable synchronization.
4.Meet the needs of different vehicles repair and detection.
5.One button to adjust balance and upper return oil, prevent oil cylinder rust.
Specifications Table
Lifting Capacity | 3500kg |
Lifting Height | 1850mm |
Min. Height | 105mm |
Lifting Time | 70s-90s |
Length of The Platform | 1450mm |
Platform Width | 635mm |
Motor Power | 3.0kw-380v or 3.0kw-220v |
Oil Pressure Rating | 24MPa |
Air Pressure | 0.6-0.8MPa |
Weight | 850kg |
Dimension
