Double tilt, Box structure with steel plate 10mm+10mm
Platform Length: 6000mm
Platform Width: 2200mm
Tower Pulling Capacity: 95 KN/10 Tons
Max. Lifting Capacity: 3500KG
Product Details
1. 86'' /2200mm wide deck is perfect for light trucks, SUV or Pickups, etc full-frame vehicles.
2. Over 200 tie-down opening for virtually unlimited anchoring.
3. True 360° pulling capability.
4. 3500kg/7716 lbs, 4500kg/10000 lbs, 5500kg/12000 lbs/ or 6000kg/13500 lbs lift capacity for more options
5. Heavy duty towers for strong pulling capacity.
Model | M-35 |
Type | Double tilt |
Platform Length | 6000mm |
Platform Width | 2200mm |
Platform Height | 300mm-1050mm |
Tower Pulling Capacity | 95 KN/10 Tons |
Max. Lifting Capacity | 3500KG |
Pulling Tower Working Range | 3600 |
Hydraulic Pressure | 70MPa(10000psi) |
Pneumatic Pressure | 0.8MPa |
Total Weight | 2500KG |
